StarLEDs - T-3 1/4 (10x25mm) E10 LED AC/DC mit Einweggleichrichter / with half-wave rectifier
StarLEDs - T-3 1/4 (10x25mm) E10 LED AC/DC mit Brückengleichrichter / with bridge rectifier
StarLEDs - T-3 1/4 (10x25mm) E10 LED 130/230V AC
Part Number Colour Voltage Typ. Current Typ. Lumi. Intensity
18601350 red 24V AC/DC 9mA AC / 17mA DC 400mcd
18601351 green 24V AC/DC 9mA AC / 17mA DC 2550mcd
18601352 yellow 24V AC/DC 9mA AC / 17mA DC 340mcd
18601357 blue 24V AC/DC 9mA AC / 17mA DC 780mcd
1860135W3 white clear 24V AC/DC 3mA AC / 6mA DC 1800mcd
1860135W3D white diffused 24V AC/DC 3mA AC / 6mA DC 900mcd
18601450 red 28V AC/DC 9mA AC / 17mA DC 400mcd
18601451 green 28V AC/DC 9mA AC / 17mA DC 2550mcd
18601452 yellow 28V AC/DC 9mA AC / 17mA DC 340mcd
18601457 blue 28V AC/DC 9mA AC / 17mA DC 780mcd
1860145W3 white clear 28V AC/DC 2,5mA AC / 5mA DC 1500mcd
1860145W3D white diffused 28V AC/DC 2,5mA AC / 5mA DC 750mcd
Lichtstärkedaten der verwendeten LED bei DC-Betrieb / Luminous intensity data of the LED on direct voltage
Passender Lampenzieher: Bestell-Nr. 55001250 / A suitable lamp remover: part number 55001250
Andere Spannungen auf Anfrage / Other voltages on request
Part Number Colour Voltage Typ. Current Typ. Lumi. Intensity
18603350 red 24V AC/DC 15mA AC/DC 350mcd
18603351 green 24V AC/DC 15mA AC/DC 2250mcd
18603352 yellow 24V AC/DC 15mA AC/DC 300mcd
18603357 blue 24V AC/DC 15mA AC/DC 680mcd
1860335W3 white clear 24V AC/DC 7mA AC/DC 2100mcd
1860335W3D white diffused 24V AC/DC 7mA AC/DC 1050mcd
18603450 red 28V AC/DC 13mA AC/DC 300mcd
18603451 green 28V AC/DC 13mA AC/DC 1950mcd
18603452 yellow 28V AC/DC 13mA AC/DC 270mcd
18603457 blue 28V AC/DC 13mA AC/DC 590mcd
1860345W3 white clear 28V AC/DC 5mA AC/DC 1500mcd
1860345W3D white diffused 28V AC/DC 5mA AC/DC 750mcd
Passender Lampenzieher: Bestell-Nr. 55001250 / A suitable lamp remover: part number 55001250
Andere Spannungen auf Anfrage / Other voltages on request
Part Number Colour Voltage Typ. Current Typ. Lumi. Intensity
18607130 red 130V AC 5mA AC 180mcd
18607131 green 130V AC 5mA AC 750mcd
18607132 yellow 130V AC 5mA AC 160mcd
18607137 blue 130V AC 5mA AC 230mcd
1860713W3 white clear 130V AC 2mA AC 600mcd
1860713W3D white diffused 130V AC 2mA AC 300mcd
18607230 red 230V AC 3mA AC 120mcd
18607231 green 230V AC 3mA AC 450mcd
18607232 yellow 230V AC 3mA AC 110mcd
18607237 blue 230V AC 3mA AC 200mcd
1860723W3 white clear 230V AC 1,5mA AC 450mcd
1860723W3D white diffused 230V AC 1,5mA AC 225mcd
Die 130V AC StarLED ist zum direkten Anschluss an die Versorgungsspannung von 130V AC dimensioniert. Ein Betrieb an einer höheren
Versorgungsspannung mittels handelsüblicher Lampenfassungselemente mit intergriertem Vorwiderstand ist nicht zulässig.
The 130V AC StarLED has been developed to run on a supply voltage of 130V AC only. An operation at a higher supply voltage using
commercial lampholders with integrated resistor is not allowed.
Passender Lampenzieher: Bestell-Nr. 55001250 / A suitable lamp remover: part number 55001250
Andere Spannungen auf Anfrage / Other voltages on request
ø 10 max.
25 max.
ø 10 max.
25 max.
ø 10 max.
25 max.
LED Lampen für Signalisation
LED Lamps for Signalisation
