BI-PIN
TELEPHONE
SLIDE
MIDGET
FLANGE
WEDGE
BASE
MIDGET
GROOVE
BAYONET
SCREW
ZUBEHÖR
ACCESSORIES
32
Mega StarLEDs - T-3 1/4 (10x25mm) E10 3x3mm LED AC/DC mit Einweggleichrichter /
with half-wave rectifier
Mega StarLEDs - T-3 1/4 (10x25mm) E10 3x3mm LED 130/230V AC
Part Number
Colour
Voltage
Typ. Current
Typ. Lumi. Intensity
18621350
red
24V AC/DC
9mA AC / 17mA DC
3x 400mcd
18621351
green
24V AC/DC
5mA AC / 10mA DC
3x 1500mcd
18621352
yellow
24V AC/DC
9mA AC / 17mA DC
3x 340mcd
18621357
blue
24V AC/DC
9mA AC / 17mA DC
3x 780mcd
1862135W3
white clear
24V AC/DC
4mA AC / 8mA DC
3x 2400mcd
1862135W3D
white diffused
24V AC/DC
4mA AC / 8mA DC
3x 1200mcd
18621450
red
28V AC/DC
9mA AC / 17mA DC
3x 400mcd
18621451
green
28V AC/DC
5mA AC / 10mA DC
3x 1500mcd
18621452
yellow
28V AC/DC
9mA AC / 17mA DC
3x 340mcd
18621457
blue
28V AC/DC
9mA AC / 17mA DC
3x 780mcd
1862145W3
white clear
28V AC/DC
3,5mA AC / 7mA DC
3x 2100mcd
1862145W3D
white diffused
28V AC/DC
3,5mA AC / 7mA DC
3x 1050mcd
Lichtstärkedaten der verwendeten LED bei DC-Betrieb /
Luminous intensity data of the LED on direct voltage
Passender Lampenzieher: Bestell-Nr. 55001250 /
A suitable lamp remover: part number 55001250
Andere Spannungen auf Anfrage /
Other voltages on request
Part Number
Colour
Voltage
Typ. Current
Typ. Lumi. Intensity
18627130
red
130V AC
5mA AC
3x 180mcd
18627131
green
130V AC
5mA AC
3x 750mcd
18627132
yellow
130V AC
5mA AC
3x 160mcd
18627137
blue
130V AC
5mA AC
3x 230mcd
1862713W3
white clear
130V AC
2mA AC
3x 600mcd
1862713W3D
white diffused
130V AC
2mA AC
3x 300mcd
18627230
red
230V AC
3mA AC
3x 120mcd
18627231
green
230V AC
3mA AC
3x 450mcd
18627232
yellow
230V AC
3mA AC
3x 110mcd
18627237
blue
230V AC
3mA AC
3x 200mcd
1862723W3
white clear
230V AC
1,5mA AC
3x 450mcd
1862723W3D
white diffused
230V AC
1,5mA AC
3x 225mcd
Die 130V AC StarLED ist zum direkten Anschluss an die Versorgungsspannung von 130V AC dimensioniert. Ein Betrieb an einer höheren
Versorgungsspannung mittels handelsüblicher Lampenfassungselemente mit intergriertem Vorwiderstand ist nicht zulässig.
The 130V AC StarLED has been developed to run on a supply voltage of 130V AC only. An operation at a higher supply voltage using
commercial lampholders with integrated resistor is not allowed.
Passender Lampenzieher: Bestell-Nr. 55001250 /
A suitable lamp remover: part number 55001250
Andere Spannungen auf Anfrage /
Other voltages on request
ø 10
25
ø 10
ø 10
25
ø 10
Mega StarLEDs - T-5 (16x35mm) E14 3x3mm LED AC/DC mit Brückengleichrichter /
with bridge rectifier
Part Number
Colour
Voltage
Typ. Current
Typ. Lumi. Intensity
18636350
red
24V AC/DC
17mA AC/DC
3x 400mcd
18636351
green
24V AC/DC
15mA AC/DC
3x 2250mcd
18636352
yellow
24V AC/DC
17mA AC/DC
3x 340mcd
18636357
blue
24V AC/DC
15mA AC/DC
3x 680mcd
1863635W3
white clear
24V AC/DC
7mA AC/DC
3x 2100mcd
1863635W3D
white diffused
24V AC/DC
7mA AC/DC
3x 1050mcd
18636450
red
28V AC/DC
17mA AC/DC
3x 400mcd
18636451
green
28V AC/DC
16mA AC/DC
3x 2400mcd
18636452
yellow
28V AC/DC
17mA AC/DC
3x 340mcd
18636457
blue
28V AC/DC
16mA AC/DC
3x 720mcd
1863645W3
white clear
28V AC/DC
7mA AC/DC
3x 2100mcd
1863645W3D
white diffused
28V AC/DC
7mA AC/DC
3x 1050mcd
Andere Spannungen auf Anfrage /
Other voltages on request
LED Lampen für Signalisation
LED Lamps for Signalisation
