23 / 77
BI-PIN
TELEPHONE
SLIDE
MIDGET
FLANGE
WEDGE
BASE
MIDGET
GROOVE
BAYONET
SCREW
ZUBEHÖR
ACCESSORIES
23
StarLEDs - T-1 3/4 (6mm) S5,7s (Midget Groove) LED AC/DC mit Einweggleichrichter /
with half-wave rectifier
StarLEDs - T-1 3/4 (6mm) S5,7s (Midget Groove) LED AC/DC (ohne Reflektor) mit Einweggleichrichter /
(without reflector) with half-wave rectifier
Part Number
Colour
Voltage
Typ. Current
Typ. Lumi. Intensity
1512135UR3
red
24V AC/DC
7mA AC / 14mA DC
330mcd
1512135UG3
green
24V AC/DC
7mA AC / 14mA DC
2100mcd
1512135UY3
yellow
24V AC/DC
7mA AC / 14mA DC
280mcd
1512135B3
blue
24V AC/DC
7mA AC / 14mA DC
650mcd
1512135W3
white clear
24V AC/DC
2,5mA AC / 5mA DC
1500mcd
1512135W3D
white diffused
24V AC/DC
2,5mA AC / 5mA DC
750mcd
1512135L3
warm white
24V AC/DC
7mA AC / 14mA DC
1260mcd
1512145UR3
red
28V AC/DC
7mA AC / 14mA DC
330mcd
1512145UG3
green
28V AC/DC
7mA AC / 14mA DC
2100mcd
1512145UY3
yellow
28V AC/DC
7mA AC / 14mA DC
280mcd
1512145B3
blue
28V AC/DC
7mA AC / 14mA DC
650mcd
1512145W3
white clear
28V AC/DC
2,5mA AC / 5mA DC
1500mcd
1512145W3D
white diffused
28V AC/DC
2,5mA AC / 5mA DC
750mcd
1512145L3
warm white
28V AC/DC
7mA AC / 14mA DC
1260mcd
Lichtstärkedaten der verwendeten LED bei DC-Betrieb /
Luminous intensity data of the LED on direct voltage
Passender Lampenzieher: Bestell-Nr. 55000112 /
A suitable lamp remover: part number 55000112
Andere Spannungen auf Anfrage /
Other voltages on request
Part Number
Colour
Voltage
Typ. Current
Typ. Lumi. Intensity
1512535UR3
red
24V AC/DC
7mA AC / 14mA DC
330mcd
1512535UG3
green
24V AC/DC
7mA AC / 14mA DC
2100mcd
1512535UY3
yellow
24V AC/DC
7mA AC / 14mA DC
280mcd
1512535B3
blue
24V AC/DC
7mA AC / 14mA DC
650mcd
1512535W3
white clear
24V AC/DC
2,5mA AC / 5mA DC
1500mcd
1512535W3D
white diffused
24V AC/DC
2,5mA AC / 5mA DC
750mcd
1512535L3
warm white
24V AC/DC
7mA AC / 14mA DC
1260mcd
1512545UR3
red
28V AC/DC
7mA AC / 14mA DC
330mcd
1512545UG3
green
28V AC/DC
7mA AC / 14mA DC
2100mcd
1512545UY3
yellow
28V AC/DC
7mA AC / 14mA DC
280mcd
1512545B3
blue
28V AC/DC
7mA AC / 14mA DC
650mcd
1512545W3
white clear
28V AC/DC
2,5mA AC / 5mA DC
1500mcd
1512545W3D
white diffused
28V AC/DC
2,5mA AC / 5mA DC
750mcd
1512545L3
warm white
28V AC/DC
7mA AC / 14mA DC
1260mcd
Lichtstärkedaten der verwendeten LED bei DC-Betrieb /
Luminous intensity data of the LED on direct voltage
Passender Lampenzieher: Bestell-Nr. 55000112 /
A suitable lamp remover: part number 55000112
Andere Spannungen auf Anfrage /
Other voltages on request
ø 6,1 max.
16 max.
StarLEDs - T-1 3/4 (6mm) S5,7s (Midget Groove) LED DC (ohne Reflektor) zweifarbig /
(without reflector) bi-colour
Part Number
Colour
Voltage
Typ. Current
Typ. Lumi. Intensity
1512535URG
red/green
24V DC
15/14mA DC
600/630mcd
1512535UGY
green/yellow
24V DC
14/15mA DC
630/375mcd
1512535URY
red/yellow
24V DC
15/15mA DC
600/375mcd
1512535UGB
green/blue
24V DC
14/14mA DC
630/105mcd
1512545URG
red/green
28V DC
15/14mA DC
600/630mcd
1512545UGY
green/yellow
28V DC
14/15mA DC
630/375mcd
1512545URY
red/yellow
28V DC
15/15mA DC
600/375mcd
1512545UGB
green/blue
28V DC
14/14mA DC
630/105mcd
Passender Lampenzieher: Bestell-Nr. 55000112 /
A suitable lamp remover: part number 55000112
Andere Spannungen auf Anfrage /
Other voltages on request
LED Lampen für Signalisation
LED Lamps for Signalisation
