18 / 77
BI-PIN
TELEPHONE
SLIDE
MIDGET
FLANGE
WEDGE
BASE
MIDGET
GROOVE
BAYONET
SCREW
ZUBEHÖR
ACCESSORIES
18
StarLEDs - T-1 (3mm) Bi-Pin LED AC/DC mit Einweggleichrichter /
with half-wave rectifier
StarLEDs - T-1 3/4 (6mm) Bi-Pin LED AC/DC mit Einweggleichrichter /
with half-wave rectifier
Part Number
Colour
Voltage
Typ. Current
Typ. Lumi. Intensity
15015350
red
24V AC/DC
5mA AC / 10mA DC
230mcd
15015351
green
24V AC/DC
5mA AC / 10mA DC
1500mcd
15015352
yellow
24V AC/DC
5mA AC / 10mA DC
200mcd
15015357
blue
24V AC/DC
5mA AC / 10mA DC
480mcd
1501535W3
white clear
24V AC/DC
2mA AC / 4mA DC
1200mcd
1501535W3D
white diffused
24V AC/DC
2mA AC / 4mA DC
600mcd
15015450
red
28V AC/DC
5mA AC / 10mA DC
230mcd
15015451
green
28V AC/DC
5mA AC / 10mA DC
1500mcd
15015452
yellow
28V AC/DC
5mA AC / 10mA DC
200mcd
15015457
blue
28V AC/DC
5mA AC / 10mA DC
480mcd
1501545W3
white clear
28V AC/DC
2mA AC / 4mA DC
1200mcd
1501545W3D
white diffused
28V AC/DC
2mA AC / 4mA DC
600mcd
Lichtstärkedaten der verwendeten LED bei DC-Betrieb /
Luminous intensity data of the LED on direct voltage
Passender Lampenzieher: Bestell-Nr. 55000112 /
A suitable lamp remover: part number 55000112
Andere Spannungen auf Anfrage /
Other voltages on request
Part Number
Colour
Voltage
Typ. Current
Typ. Lumi. Intensity
15095350
red
24V AC/DC
7mA AC / 14mA DC
330mcd
15095351
green
24V AC/DC
7mA AC / 14mA DC
2100mcd
15095352
yellow
24V AC/DC
7mA AC / 14mA DC
280mcd
15095357
blue
24V AC/DC
7mA AC / 14mA DC
650mcd
1509535W3
white clear
24V AC/DC
2,5mA AC / 5mA DC
1500mcd
1509535W3D
white diffused
24V AC/DC
2,5mA AC / 5mA DC
750mcd
15095450
red
28V AC/DC
7mA AC / 14mA DC
330mcd
15095451
green
28V AC/DC
7mA AC / 14mA DC
2100mcd
15095452
yellow
28V AC/DC
7mA AC / 14mA DC
280mcd
15095457
blue
28V AC/DC
7mA AC / 14mA DC
650mcd
1509545W3
white clear
28V AC/DC
2,5mA AC / 5mA DC
1500mcd
1509545W3D
white diffused
28V AC/DC
2,5mA AC / 5mA DC
750mcd
Lichtstärkedaten der verwendeten LED bei DC-Betrieb /
Luminous intensity data of the LED on direct voltage
Passender Lampenzieher: Bestell-Nr. 55000112 /
A suitable lamp remover: part number 55000112
Andere Spannungen auf Anfrage /
Other voltages on request
ø 0,5
2,54
10
ø 3,8
6,35-6,85
3,17
16 max.
ø 6,1 max.
6,35-6,85
LED Lampen für Signalisation
LED Lamps for Signalisation
