BI-PIN

TELEPHONE

SLIDE

MIDGET

FLANGE

WEDGE

BASE

MIDGET

GROOVE

BAYONET

SCREW

ZUBEHÖR

ACCESSORIES

22

StarLEDs - T-1 1/2 (5mm) W2x4,6d (Wedge Base) LED AC/DC mit Einweggleichrichter /

with half-wave rectifier

StarLEDs - T-3 1/4 (10mm) W2,1x9,5d (Wedge Base) LED AC/DC mit Einweggleichrichter /

with half-wave rectifier

Part Number

Colour

Voltage

Typ. Current

Typ. Lumi. Intensity

1511A35UR3

red

24V AC/DC

5mA AC / 10mA DC

230mcd

1511A35UG3

green

24V AC/DC

5mA AC / 10mA DC

1500mcd

1511A35UY3

yellow

24V AC/DC

5mA AC / 10mA DC

200mcd

1511A35B3

blue

24V AC/DC

5mA AC / 10mA DC

480mcd

1511A35W3

white clear

24V AC/DC

2mA AC / 4mA DC

1200mcd

1511A35W3D

white diffused

24V AC/DC

2mA AC / 4mA DC

600mcd

1511A35L3

warm white

24V AC/DC

5mA AC / 10mA DC

900mcd

1511A45UR3

red

28V AC/DC

5mA AC / 10mA DC

230mcd

1511A45UG3

green

28V AC/DC

5mA AC / 10mA DC

1500mcd

1511A45UY3

yellow

28V AC/DC

5mA AC / 10mA DC

200mcd

1511A45B3

blue

28V AC/DC

5mA AC / 10mA DC

480mcd

1511A45W3

white clear

28V AC/DC

2mA AC / 4mA DC

1200mcd

1511A45W3D

white diffused

28V AC/DC

2mA AC / 4mA DC

600mcd

1511A45L3

warm white

28V AC/DC

5mA AC / 10mA DC

900mcd

Lichtstärkedaten der verwendeten LED bei DC-Betrieb /

Luminous intensity data of the LED on direct voltage

Passender Lampenzieher: Bestell-Nr. 55000112 /

A suitable lamp remover: part number 55000112

Andere Spannungen auf Anfrage /

Other voltages on request

Part Number

Colour

Voltage

Typ. Current

Typ. Lumi. Intensity

1511B35UR3

red

24V AC/DC

7mA AC / 14mA DC

330mcd

1511B35UG3

green

24V AC/DC

7mA AC / 14mA DC

2100mcd

1511B35UY3

yellow

24V AC/DC

7mA AC / 14mA DC

280mcd

1511B35B3

blue

24V AC/DC

7mA AC / 14mA DC

650mcd

1511B35W3

white clear

24V AC/DC

2,5mA AC / 5mA DC

1500mcd

1511B35W3D

white diffused

24V AC/DC

2,5mA AC / 5mA DC

750mcd

1511B35L3

warm white

24V AC/DC

7mA AC / 14mA DC

1260mcd

1511B45UR3

red

28V AC/DC

7mA AC / 14mA DC

330mcd

1511B45UG3

green

28V AC/DC

7mA AC / 14mA DC

2100mcd

1511B45UY3

yellow

28V AC/DC

7mA AC / 14mA DC

280mcd

1511B45B3

blue

28V AC/DC

7mA AC / 14mA DC

650mcd

1511B45W3

white clear

28V AC/DC

2,5mA AC / 5mA DC

1500mcd

1511B45W3D

white diffused

28V AC/DC

2,5mA AC / 5mA DC

750mcd

1511B45L3

warm white

28V AC/DC

7mA AC / 14mA DC

1260mcd

Lichtstärkedaten der verwendeten LED bei DC-Betrieb /

Luminous intensity data of the LED on direct voltage

Passender Lampenzieher: Bestell-Nr. 55001250 /

A suitable lamp remover: part number 55001250

Andere Spannungen auf Anfrage /

Other voltages on request

ø 6,1 max.

18,5 max.

14,5 max.

ø 10,1 max.

20,7 max.

LED Lampen für Signalisation

LED Lamps for Signalisation
