EINBAUDURCHMESSER

MOUNTING HOLE

ZUBEHÖR

ACCESSORIES

59

LED Signalleuchten

LED Panel Mount Indicators

Standardreflektor 130/230V AC mit Berührungsschutzhülse IP67 /

Standard bezel 130/230V AC with protection tube IP67

Part Number

Colour

Voltage

Typ. Current

Typ. Lumi. Intensity

Hochglanzverchromter Metallreflektor /

Satin chrome bezel

19350130

red

130V AC

6mA AC

47mcd

19350131

green

130V AC

6mA AC

34mcd

19350133

yellow

130V AC

6mA AC

27mcd

19350135

ultra-green

130V AC

6mA AC

660mcd

19350137

blue

130V AC

6mA AC

196mcd

1935013W

white

130V AC

4mA AC

700mcd

19350230

red

230V AC

3mA AC

18mcd

19350231

green

230V AC

3mA AC

11mcd

19350233

yellow

230V AC

3mA AC

8mcd

19350235

ultra-green

230V AC

3mA AC

330mcd

19350237

blue

230V AC

3mA AC

98mcd

1935023W

white

230V AC

2,5mA AC

440mcd

Schwarzverchromter Metallreflektor /

Black chrome bezel

19351130

red

130V AC

6mA AC

47mcd

19351131

green

130V AC

6mA AC

34mcd

19351133

yellow

130V AC

6mA AC

27mcd

19351135

ultra-green

130V AC

6mA AC

660mcd

19351137

blue

130V AC

6mA AC

196mcd

1935113W

white

130V AC

4mA AC

700mcd

19351230

red

230V AC

3mA AC

18mcd

19351231

green

230V AC

3mA AC

11mcd

19351233

yellow

230V AC

3mA AC

8mcd

19351235

ultra-green

230V AC

3mA AC

330mcd

19351237

blue

230V AC

3mA AC

98mcd

1935123W

white

230V AC

2,5mA AC

440mcd

Mattverchromter Metallreflektor /

Matt chrome bezel

19352130

red

130V AC

6mA AC

47mcd

19352131

green

130V AC

6mA AC

34mcd

19352133

yellow

130V AC

6mA AC

27mcd

19352135

ultra-green

130V AC

6mA AC

660mcd

19352137

blue

130V AC

6mA AC

196mcd

1935213W

white

130V AC

4mA AC

700mcd

19352230

red

230V AC

3mA AC

18mcd

19352231

green

230V AC

3mA AC

11mcd

19352233

yellow

230V AC

3mA AC

8mcd

19352235

ultra-green

230V AC

3mA AC

330mcd

19352237

blue

230V AC

3mA AC

98mcd

1935223W

white

230V AC

2,5mA AC

440mcd

Maximale Frontplattenstärke 11mm /

Maximum panel thickness 11mm

Andere Spannungen auf Anfrage /

Other voltages on request

18

13,5

SW 17

5

ø 16

M 14 x 1

2,5

9

2,8 x 0,8

11,5

23,5

M 14 x 1

50,5

13,5

SW 17

5

ø 16

2,5

21

11,5

Berührungsschutzhülse

protection tube

Die 130VAC und 230VACVersionen werdengrundsätzlich mit

Berührungsschutzhülse geliefert.

Ingeneralwe supply the130VACand230VACversionswitha

protection tube.
