16mm

8mm

12mm

14mm

16mm

19mm

22mm

EINBAUDURCHMESSER

MOUNTING HOLE

ZUBEHÖR

ACCESSORIES

67

LED Signalleuchten

LED Panel Mount Indicators

Standardreflektor flache Linse mit Vorwiderstand und Einweggleichrichter IP67 /

Standard bezel flat lens with resistor and half-wave rectifier IP67

Part Number

Colour

Voltage

Typ. Current

Typ. Lumi. Intensity

Hochglanzverchromter Metallreflektor /

Satin chrome bezel

19710250

red

12V AC/DC

8mA AC / 16mA DC

1500mcd

19710255

green

12V AC/DC

7mA AC / 14mA DC

1200mcd

19710252

yellow

12V AC/DC

8mA AC / 16mA DC

1000mcd

19710257

blue

12V AC/DC

7mA AC / 14mA DC

350mcd

1971025W

white

12V AC/DC

2,5mA AC / 5mA DC

750mcd

19710350

red

24V AC/DC

8mA AC / 16mA DC

1500mcd

19710355

green

24V AC/DC

7mA AC / 14mA DC

1200mcd

19710352

yellow

24V AC/DC

8mA AC / 16mA DC

1000mcd

19710357

blue

24V AC/DC

7mA AC / 14mA DC

350mcd

1971035W

white

24V AC/DC

2,5mA AC / 5mA DC

750mcd

Schwarzverchromter Metallreflektor /

Black chrome bezel

19711250

red

12V AC/DC

8mA AC / 16mA DC

1500mcd

19711255

green

12V AC/DC

7mA AC / 14mA DC

1200mcd

19711252

yellow

12V AC/DC

8mA AC / 16mA DC

1000mcd

19711257

blue

12V AC/DC

7mA AC / 14mA DC

350mcd

1971125W

white

12V AC/DC

2,5mA AC / 5mA DC

750mcd

19711350

red

24V AC/DC

8mA AC / 16mA DC

1500mcd

19711355

green

24V AC/DC

7mA AC / 14mA DC

1200mcd

19711352

yellow

24V AC/DC

8mA AC / 16mA DC

1000mcd

19711357

blue

24V AC/DC

7mA AC / 14mA DC

350mcd

1971135W

white

24V AC/DC

2,5mA AC / 5mA DC

750mcd

Mattverchromter Metallreflektor /

Matt chrome bezel

19712250

red

12V AC/DC

8mA AC / 16mA DC

1500mcd

19712255

green

12V AC/DC

7mA AC / 14mA DC

1200mcd

19712252

yellow

12V AC/DC

8mA AC / 16mA DC

1000mcd

19712257

blue

12V AC/DC

7mA AC / 14mA DC

350mcd

1971225W

white

12V AC/DC

2,5mA AC / 5mA DC

750mcd

19712350

red

24V AC/DC

8mA AC / 16mA DC

1500mcd

19712355

green

24V AC/DC

7mA AC / 14mA DC

1200mcd

19712352

yellow

24V AC/DC

8mA AC / 16mA DC

1000mcd

19712357

blue

24V AC/DC

7mA AC / 14mA DC

350mcd

1971235W

white

24V AC/DC

2,5mA AC / 5mA DC

750mcd

Lichtstärkedaten der verwendeten LED bei DC-Betrieb /

Luminous intensity data of the LED on direct voltage

Maximale Frontplattenstärke 11mm /

Maximum panel thickness 11mm

Andere Spannungen auf Anfrage /

Other voltages on request

9

41

±

2

SW 22

3,5

ø 22

M 19 x 1

2,8 x 0,8
